Internal Reference:
T030601
Accessories
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.
Optional products
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.
Alternative products
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.
Specification
| System | |
|---|---|
| Operating system | Android 8.1 |
| Technical parameters | |
|---|---|
| Operator display | 15.6" multi-touch capacitive touch screen 1920x1080px |
| Customer display | 10.1" LCD screen 1024x600px |
| RAM | 2GB |
| Datastorage | 16GB eMMC |
| CPU | Processor with architecture Cortex-A17, Quad-Core 1.8GHz, RK3288 |
| Color | White |
| Connectivity | |
|---|---|
| Communication interface | 4xUSB 2.0, 1xRJ45 Ethernet 100M, 1xRJ9, 1xRJ11 |
| Wi-Fi | 802.11 b/g/n (Optional) |
| Bluetooth | BT4.0BLE |
| Physical characteristics | |
|---|---|
| Dimensions (L x W x D) | 379,2 x 179,1 x 315,5 mm |
| Weight | 2,84 kg |
| Storage and operating environment | |
|---|---|
| Operating temperature | -5°C – 50°C, 10%~90% non-condensing |
| Storage temperature | -20°C – 70°C, 5%~90% non-condensing |
| Uncategorized | |
|---|---|
| Cooling | passive |
| Surface treatment | plastic, aluminium |
| Degree of IP protection | IP30 |
| Power supply | Input: 100-240V AC 50/60Hz, Output: 24V/2A |
| Product certification | CCC, FCC, CE |
